Area Summary
- Total Area:3440 Sq. Ft.
- Main Floor:1360 Sq. Ft.
- Upper Floor:1340 Sq. Ft.
- Lower Floor:740 Sq. Ft.
- Garage Floor:640 Sq. Ft.
General Information
- Stories:3
- Width:60'-0"
- Depth:42'-0"
- Height:27'-6"
Architectural Style
- Country
- Farmhouse
- Traditional
Number of Rooms
- Bedrooms:5
- Full Baths:3
- Half Baths:1
Garage
- Garage Size:3
- Garage Door Location:Front
Roof Pitches
- Primary:6:12
- Secondary:12:12
Wall Heights
- Main:9'-0"
- Upper:8'-0"
- Lower:9'-0"
Foundation Type
- Daylight Basement
Roof Framing
- Trusses
Floor Load
- Live (lbs):40 PSF
- Dead (lbs):10 PSF
Roof Load
- Live (lbs):25 PSF
- Dead (lbs):15 PSF
- Wind:85 MPH
Design Features
- Bonus Space @ , Upper & Lower Floor
- Front Porch
- Great Room
- Laundry Room @ & Upper Floor
- Master Bedroom @ Upper Floor Rear
